Ricoh GEN6 MH5320 New Printhead (Cable: 447mm)

Ricoh GEN6 Printhead (MH5320 Series) – High Precision & Long Life

The Ricoh GEN6 MH5320 series printhead is engineered for UV-based inks, delivering superior print quality and outstanding reliability. With a service life more than twice as long as the previous MH5421/MH5441 models, this printhead ensures long-lasting performance and reduced downtime.

This model is the 2-color version (MH5320), while the 4-color version (MH5340) is also available. Featuring a minimum 5pl droplet size and improved jetting accuracy, it produces smooth, high-resolution prints without visible graininess. Equipped with 1,280 nozzles, the MH5320 achieves a native resolution of 600 dpi, while its grayscale jetting at up to 50 kHz boosts productivity without compromising image quality.

The printhead includes a 447 mm cable (total length 500 mm) and is composed of two parts: J376-03 (head) and J352-04 (445 mm cable).

Key Features

• Long service life – over 2x longer than previous Ricoh models

• High-resolution 600 dpi printing with 1,280 nozzles

• Small 5pl droplet size for smooth, detailed images

• Grayscale capability up to 50 kHz for faster throughput

• Compatible with UV, solvent, aqueous, and other ink types

• Integrated heater and thermistor for stable ink performance

• Original Ricoh part, manufactured in Japan

Technical Specifications

• Method: Piston pusher with metallic diaphragm plate

• Print width: 54.1 mm (2.1")

• Dimensions: 89 (W) × 66.3 (D) × 24.51 mm (H)

• Weight: 228 g (with 45C cable)

• Materials: Stainless steel, nickel alloy, epoxy adhesive

• Nozzle plate surface: Coated SST

• Number of nozzles: 4 × 320 (total 1,280)

• Nozzle spacing: 0.1693 mm

• Row spacing: A: 1.101 mm / B: 11.8411 mm

• Compatible inks: UV, solvent, aqueous, others

• Nozzle density: Up to 600 npi

• Max. number of color inks: 2

• Drop volume: 5 pl (binary) / 5–15 pl (grayscale)

• Jetting frequency: 50 kHz (3 levels) / 40 kHz (4 levels)

• Grayscale: 4 levels

• Viscosity range: 10–12 mPa·s

• Surface tension: 28–35 mN/m

• Temperature control: Integrated heater & thermistor

• Operating temperature: Up to 60°C

• Ink ports: Yes

• Cable length: 447 mm (500 mm including head)

Country of Origin: Japan
Warranty: Manufacturer warranty included

Printer Compatibility

• d.gen Teleios Omni Pro

• Hollanders ColorBooster 320

• M5000

• MC2512RV

• PrintJet HYB2000

• SG6 2030
