Original Mimaki GEN5 M022650 New Print Head

Original Mimaki SWJ-320 GEN5 Assy Packaging – M022650

The Mimaki SWJ-320 GEN5 Assy Packaging (Part No. M022650) is a genuine original part designed for Mimaki SWJ-320 printers, replacing the previous model M012639. This assembly includes tubes, valves, ink connectors, and brackets, ensuring stable ink delivery and reliable printer performance.

Built with premium materials and advanced piezo technology, the GEN5 printhead offers exceptional precision, durability, and high-speed printing capabilities. It is engineered to meet the demands of professional large-format printing, delivering consistent output and extended service life.

Key Features

• Original Mimaki Part Number: M022650 (replaces M012639)

• Complete assembly including tubes, valves, ink connectors, and brackets

• Manufacturer warranty included

• Made in Japan – trusted quality and durability

Product Specifications

• Dimensions: 89 x 25 x 69 mm (excluding cables)

• Head Materials: Stainless Steel (SST), Nickel Alloy, Epoxy Adhesive

• Nozzle Plate Surface: Coated SST

• Nozzles: 4 x 320 (total 1,280 nozzles)

• Nozzle Spacing: 0.1693 mm

• Nozzle Density: Up to 600 npi

• Piezo Type: D33 Stacked PZT

• Temperature Control: Integrated Heater & Thermistor

• Operating Temperature Range: Up to 80°C

• Native Drop Volume: 7 pl

• Drop Volume Range: 7 – 35 pl

• Drop Velocity: 7 m/s

• Jetting Frequency: Up to 60 kHz

• Lifetime: 100 billion actuations per nozzle

Printer Compatibility

• Mimaki SWJ-320

• MTEX 5032 HS
